Shopsmith Large Format Drawings, Illustrations and More

everettdavis

I misread the post in the other forum.

Everett

everettdavis

At the request of others I reorganized the first page to place the My Google Drive near the top so folks would not have to scroll to find it as I added new content and revised the descriptions.

There is valuable information on this page below the My Google Drive link that folks should read through.

Everett

everettdavis

November 29, 2019 under My Google Drive link find "Shopsmith Planer with a manual feed mechanism.pdf" in folder titled Planers (All 3)'

I am pursuing a machinist locally that will allow me to cobble together a manual feed mechanism using a combination of existing parts available from Shopsmith and openly available parts from other applications from McMaster Carr and other vendors.

Once I finish, I will post how it's done, where to find the parts, and information for you to to machine one for yourself if desired.

Kindest Regards,

Everett

To Woodruff Key or Not to Woodruff Key.png

everettdavis

1956 Shopsmith Woodworking Course lessons

Courtesy of Doug Smith in the Facebook Shopsmith Group, I was provided copies of 1956 Shopsmith Woodworking Courses lessons 3 - 10 written by Professor Benjamin W. Spaulding, Professor Emeritus Of Industrial Arts San Jose State College.

Lesson 3 of 10 #9304

Lesson 4 of 10 #9305

Lesson 5 of 10 #9306

Lesson 6 of 10 #9307

Lesson 7 of 10 #9308

Lesson 8 of 10 #9309

Lesson 9 of 10 #9310

Lesson 10 of 10 #9311

There are pictures of the Mark 5 on the front cover.

While there are no photos, there are extensive line-art drawings and text.

Two lessons were missing:

Lesson 1 of 10 #9302 ?

Lesson 2 of 10 #9303 ?

I seek those to complete the course set I am restoring and will publish. If anyone has those two I would like to obtain 300dpi color scans of them.

Doug also provided a Montgomery Ward 1950-51 Powr-Kraft Power Tool and Welding Catalog.

It has Shopsmith 10E with accessories on the last two pages and the back cover is machine photo with R. J. De Cristoforo adjusting the blade guard.

I will be restoring just the covers and last pages on it.

Thanks for your help and thanks to Doug for sharing. These are another piece of history.

Kindest Regards,

Everett

1956 Shopsmith Woodworking Courses lessons 3 - 10.jpg

everettdavis

Woodworking Course 1956 – Professor Benjamin W. Spaulding – Lesson Three Restoration is completed and in folder titled ‘1956 Woodworking Course’ under My Google Drive link on page 1 of this thread.

Thanks to Doug Smith for providing these originals to me without cost, which made this restoration and preservation possible.

Lessons one and two were missing. Lessons three through ten will be restored.

Everett

After Cover Reduced for Forum.jpg

everettdavis

Woodworking Course 1956 – Professor Benjamin W. Spaulding – Lesson Four Restoration is completed and in folder titled ‘1956 Woodworking Course’ under My Google Drive link on page 1 of this thread.

Everett

04 Lesson Four 00 Cover for Forum.jpg

JPG

Two down, 6(8) to go. Great effort!!!!

everettdavis

James,

I have just been gifted a set of all ten already in pdf format by Martin Thomas over in the Facebook Shopsmith Owners Group. They are very clean scans and thus far very much welcomed.

Doug got me started and Martin, seeing what I was working on has refocused my efforts. I will closely examine them to take the best quality forward.

Thank you for your comments, your friendship and for being one of my Shopsmith mentors.

UPDATE: Martin's PDF scans are of such quality that I will simply rename them to reflect his contribution to this project.

I must surmise that Martin's originals are not as yellowed, or his scanner is far superior to mine. These scans are excellent and need no further work.

I have reached out to him, as I am missing Lesson 9 in his bundle of PDF's. As soon as I receive that I will add the entire collection to My Google Drive for everyone.

Blessings,

Everett

everettdavis

Martin Thomas sent me Lesson 09 and they are all now posted.

Thanks again to Doug and Martin for all your help

Everett

everettdavis

New Folder Added - Patents

File Naming Conventions I used in My Google Drive Folder - Patents

I have used one of these - Bandsaw - in the Bandsaw folder in an extensive exploration of how the bandsaw tracking system was designed and intended to work.

It has extensively reworked drawings and actual photos included, is readable, reference-able, and zoom capable. No, I have no others scheduled to rework in this manner.... but one never says never.... the urge might strike me someday!

1947.08.18 Original Shopsmith 10 - US002623269

Convertible Material Working Machine - filed 1947-08-18 granted 1952-12-30

1947.08.18 Tool Rest - US2697456

Tool Rest for Lathes - filed 1947-08-18 granted 1954-12-21

1947.08.18 Work Support Table - US2747626A

Circular Saw Work Supporting Table - filed 1947-08-18 granted 1956-05-29

1952.11.21 Drill Press Assembly - US2748627A

Drill Press Assembly - filed 1952-11-21 granted 1956-06-05

1954.04.30 Power Grip - US002759503

Work Holding and Feeding Device for Use with Table Saws - filed 1954-04-30 granted 1956-08-21

1955.03.15 Lift for Table or Tool Rest - US2945518A

Apparatus for Raising and Lowering A Saw Table or Tool Rest - filed 1955-03-15 granted 1960-07-19

1955.03.15 Mark 5 - US2927612

Combination Wood Working Machine - filed 1955-03-15 granted 1960-03-08

1955.03.15 Rip Fence for Saw Table - US002919729

Rip Fence for Saw Table - filed 1955-03-15 granted 1960.10.05

1955.11.04 Belt Sander - US002857717

Belt Sander - filed 1955-11-04 granted 1958-10-28

1956.02.08 Bandsaw - US2903027A

Blade Tracking and Guiding Mechanism Band Saw Construction - filed 1956-02-13 granted 1959-09-08

1956.07.19 Table Saw - US002945516

Tilting arbor table saw with coaxial control of elevation and tilt - filed 1956-07-19 granted 1960-12-31

1957.12.16 Moulding Head - US002896678

Blade Anchorage Means for Molding Head - filed 1957-12-16 granted 1959-07-28

1957.08.30 Saw Arbor - US002945519

Saw Arbor - filed 1957-08-30 granted 1960-07-19

1958.01.22 Mark 2 - US002964075

Woodworking Machine - filed 1958-01-22 granted 1960-12-13

1958.05.22 Sliding Table Saw - US003115166

Sliding Table Saw - filed 1958-05-22 granted 1963-12-24

1960.09.06 Radial Arm Saw - US003104687

Radial Arm Saw - filed 1960-09-06 granted 1963-09-24

1964.01.29 Mark VII Multi Purpose Power Tool - US003282309

Multi Purpose Power Tool - filed 1964-01-29 granted 1966-11-01

1982.08.16 Planer - USD276616

Planer - filed 1982-08-16 granted 1984-12-04

1982.08.16 Planer Chip Removal System - US4485859

Planer Chip Removal System - filed 1982-08-16 granted 1984-12-04

1982.08.16 Planer Mounting System - US4440204

Planer Mounting System - filed 1982-08-16 granted 1984-04-03

1982.08.16 Planer Table Assembly - US4456042

Planer Table Assembly - filed 1982-08-16 granted 1984-06-26

1982.09.02 Adjustable Featherboard - US4476757

Adjustable Featherboard - filed 1982-09-02 granted 1984-10-16

1982.09.02 Adjustable Straddle Block - US4485711

Adjustable Straddle Block - filed 1982-09-02 granted 1984-12-04

1982.09.02 Push Block - USD278790

Push Block for use in guiding work pieces during cutting operations - filed 1982-09-02 granted 1985-05-14

1982.09.02 Push Stick - USD278022

Push Stick for a table saw or the like - filed 1982-09-02 granted 1985-03-19

1983.09.14 Tilting Table - US4494591

Tilting Table for a Woodworking Tool - filed 1983-09-14 granted 1985-01-22

Referencences a Tony Fox patent

1983.11.16 Support Frame for a Power Tool - USD286538

Support Frame for a Power Tool - filed 1983-11-16 granted 1986-11-16

**curious new frame - I have not seen one produced**

1983.11.16 Headstock Elevating Apparatus - US4548246

Headstock Elevating Apparatus - filed 1983-11-16 granted 1985-10-22

1983.11.16 Headstock for a MultiPurpose Woodworking Tool - USD281431

Headstock for a MultiPurpose Woodworking Tool - filed 1983-11-16 granted 1985-11-19

**curious new headstock**

1983.11.16 Saw Table - USD281328

Saw Table - filed 1983-11-16 granted 1985-11-12

1983.11.16 Table Assembly - US4510980

Table Assembly for a Multipurpose Tool - filed 1983-11-16 granted 1985-04-16

Referencences a Tony Fox patent

1983.11.16 Workpiece Support System - US4566510

Workpiece Support System for a Power Tool - filed 1983-11-16 granted 1986-01-28

1984.06.25 Cutter Head System - US4538655

Cutter Head System - filed 1984-06-25 granted 1985-09-03

1985.01.10 Combined Guard and Dust Collector - USD292407

Combined Guard and Dust Collector for a Table Saw - filed 1985-01.10 granted 1987-10-20

1985.07.31 Miter Gage - US4658686

Miter Gage - filed 1985-07-31 granted 1987-04-21

1985.09.13 Anti-Kickback System - US4615247

Anti-Kickback System - filed 1985-09-13 granted 1986-10-07

1985.10.08 Saw Fence - US4658687

Saw Fence - filed 1985-10-08 granted 1987-04-21

1986.06.17 Lathe Duplicator - US4694713

Duplicating System for Lathe - filed 1986-06-17 granted 1987-09-22

1986.06.20 Saw Guard System - US4721023

Saw Guard System - filed 1986-06-20 granted 1988-01-26

1986.09.19 Portable Dust Collector - US4715872

Portable Dust Collector - filed 1986-09-19 granted 1987-12-29

1989.04.10 Lathe Duplicator - US4899793

Lathe Duplicator - filed 1989-04-10 granted 1990-02-13

1989.08.02 Power Module for Woodworking Tools - USD328904

Power Module for Woodworking Tools - filed 1989-08-02 granted 1992-08-25

1989.08.02 Power Station - US4972885

Power Module for Special Purpose Woodworking Tools - filed 1989-08-02 granted 1990-11-27

1989.08.10 Biscuit Joiner - US4926916

Biscuit Joiner - filed 1989-08-10 granted 1990-05-22

1989.11.29 Speed Reduction Device - US5017180

Speed Reduction Device - filed 1989-11-29 granted 1991-05-21

1989.12.11 Mitered Corner Apparatus - US5042346

Apparatus for Fabricating Accurate Mitered Corners - filed 1989-12-11 granted 1991-08-27

Jim McCann inventor - still works at in Shopsmith 2020

1990.01.22 Scroll Saw - US5058476

Scroll Saw - filed 1990-01-22 granted 1991-10-22

1990.02.23 T-Slot Table - US4989654

Woodworking Worktable Assembly Having an Extruded T-Slot - filed 1990-02-23 granted 1991-02-05

1990.02.23 Speed Increaser - US5035152

Speed Increaser for Woodworking Tools - filed 1990-02-23 granted 1991-07-30

1990.05.18 Biscuit Joiner - US5004027

Biscuit Joiner - filed 1990-05-18 granted 1991-04-02

1990.06.25 Jointer Cutter Guard with Featherboard - US5000237

Jointer Cutter Guard with Featherboard - filed 1990-06-25 granted 1991-03-19

1990.12.11 Scroll Saw - US5065652

Scroll Saw - filed 1990-12-11 granted 1991-11-19

jsburger

Very interesting. From the patent dates it looks like the '80's were the hay day of SS.

everettdavis

There are still some I am seeking.

The Sawsmith 2000 seems like it would have patented components but I haven’t found them yet.

There may be others too.

Everett

everettdavis

Added three additional patents and updated text list in post above in thread

New files in My Google Drive folder - Patents

1957.08.30 Saw Arbor - US002945519

Saw Arbor - filed 1957-08-30 granted 1960-07-19

1958.01.22 Mark 2 - US002964075

Woodworking Machine - filed 1958-01-22 granted 1960-12-13

1990.02.23 T-Slot Table - US4989654

Woodworking Worktable Assembly Having an Extruded T-Slot - filed 1990-02-23 granted 1991-02-05

Everett

everettdavis

Shopsmith 1990 Air System by Cambell Hausfeld manual v 1.01.pdf

is now in folder titled: Shopsmith 1990 Air System under My Google Drive Link in the first post in this thread.

Many thanks to Russ Chapman who provided a copy of the original 1990 manual to work from

Note printing instructions in the footer of the pages to instruct your printer to print on the size of paper in your printer. The file page size is 11" x 17"

Everett

Note: v 1.01 Includes Page 19 Troubleshooting

everettdavis

I just called and emailed customer service

About the series of spam messages above

Everett

everettdavis

everettdavis wroteI just called and emailed customer service

About the series of spam messages above

Everett

Many thanks to Shopsmith for cleaning out the Spam messages that were present in the forum overnight and to all who reported them.

Everett

JPG

everettdavis wrote
everettdavis wroteI just called and emailed customer service

About the series of spam messages above

Everett
Many thanks to Shopsmith for cleaning out the Spam messages that were present in the forum overnight and to all who reported them.

Everett

I doubt CS had anything to do with their removal! ;)

everettdavis

A friend who I spoke with extensively on the phone about a Shopsmith and Bandsaw he was considering asked me to write down the things we discussed for him as a check list of sorts.

Well, the result of that request appears below, and on My Google Drive main page. It coupled with the Buying a Used Shopsmith Revisited PDF, and What Can a Single Crosscut Tell You are used in concert.

He also complained about having to scroll down to find My Google Drive link. It now appears in the top of the original post.

Kindest Regards everyone,

Everett

jsburger

everettdavis wroteA friend who I spoke with extensively on the phone about a Shopsmith and Bandsaw he was considering asked me to write down the things we discussed for him as a check list of sorts.

Well, the result of that request appears below, and on My Google Drive main page. It coupled with the Buying a Used Shopsmith Revisited PDF, and What Can a Single Crosscut Tell You are used in concert.

He also complained about having to scroll down to find My Google Drive link. It now appears in the top of the original post.

Kindest Regards everyone,

Everett

Negotiating Price ©Everett L. Davis 2020.pdf

Very nice and well written article with very good advice.

everettdavis

Under the topic:

I never knew that was there

I was recently reminded by someone who was over in the Facebook users group that they didn’t know some of the features I built into documents I created here were even present.

They did not know that I embedded hot links in the photos I included that if double clicked on the photos, open the very thread in the Shopsmith Forums the photo came from.

It was true in the very first document I ever posted here “Buying A Used Shopsmith V2” as well as “Shopsmith Bearing Guide”, “Got Rust” and a host of other documents.

Similarly in a number of restored manuals, and the fully restored 1953 Power Tool Woodworking for Everyone (PTWFE) a 346 page Book, in addition to having an extended table of contents, the table of contents entries are active links within the document.

In the Bearing Guide, the chart at the end has hot-links for the bearings data in many cases.

Moreover, as such the entire documents are word-search capable using Ctrl+F (find) as well as being zoom capable in photos and text.

So in documents you may have downloaded months ago, there are discoveries to be made in them.

And now you know.... if you had not discovered that already.

Everett

« Previous Page Next Page »
