My first SS. SO EXCITED!

Forum for people who are new to woodworking. Feel free to ask questions or contribute.

Moderator: admin

User avatar
dgale
Platinum Member
Posts: 1007
Joined: Fri Jul 13, 2012 1:17 am
Location: Dows Prairie, CA

Post by dgale »

jhut83 wrote:It looks like the previous owner tried punching the pin out with with a screw. The screw is stuck in there and I can't drill it out. I tried using a drill press and the bit just slipped and started chewing into the aluminum. I'll have to figure something else out. In the meantime I'm bidding on a new base on ebay. Fingers crossed.
A new base is probably a good way to go - once those pins get messed up, it's tough to deal with it...as you noted, drilling it out when it's surrounded by aluminum is easier said than done. Seems like the bases can be had on E-Bay for $20 pretty regularly in good condition, so this will probably save you a lot of agravation.
jhut83
Gold Member
Posts: 50
Joined: Wed Dec 12, 2012 5:21 pm

Post by jhut83 »

dgale wrote:A new base is probably a good way to go - once those pins get messed up, it's tough to deal with it...as you noted, drilling it out when it's surrounded by aluminum is easier said than done. Seems like the bases can be had on E-Bay for $20 pretty regularly in good condition, so this will probably save you a log of agravation.
Exactly. It's just not worth the headache. I'm going to order a punch set so I'll be prepared when the new base gets here.
User avatar
fjimp
Platinum Member
Posts: 2345
Joined: Wed Jul 19, 2006 8:45 pm
Location: Lakewood, Colorado

Post by fjimp »

Wow, I have two sets of bases I would cheerfully give away. The were under my Mark V's which have been upgraded to Mark 7's. Tis a shame you aren't closer. Jim
F. Jim Parks
Lakewood, Colorado:)

When the love of power is replaced by the power of love the world will have a chance for survival.
User avatar
JPG
Platinum Member
Posts: 35457
Joined: Wed Dec 10, 2008 7:42 pm
Location: Lexington, Ky (TAMECAT territory)

Post by JPG »

Another caveat!

The greenie(and early goldies) have a slightly different base than the older versions. They were designed for the larger 1 7/8" bench tubes. The opening is NOT the difference. The difference is the side stop(s). The later stops protrude further from the side than the older ones.
╔═══╗
╟JPG ╢
╚═══╝

Goldie(Bought New SN 377425)/4" jointer/6" beltsander/12" planer/stripsander/bandsaw/powerstation /Scroll saw/Jig saw /Craftsman 10" ras/Craftsman 6" thicknessplaner/ Dayton10"tablesaw(restoredfromneighborstrashpile)/ Mark VII restoration in 'progress'/ 10
E[/size](SN E3779) restoration in progress, a 510 on the back burner and a growing pile of items to be eventually returned to useful life. - aka Red Grange
jhut83
Gold Member
Posts: 50
Joined: Wed Dec 12, 2012 5:21 pm

Post by jhut83 »

JPG40504 wrote:Another caveat!

The greenie(and early goldies) have a slightly different base than the older versions. They were designed for the larger 1 7/8" bench tubes. The opening is NOT the difference. The difference is the side stop(s). The later stops protrude further from the side than the older ones.

Ah shoot. I was bidding on a grey one. I'll have to keep looking.
User avatar
fixit
Gold Member
Posts: 439
Joined: Fri Jul 21, 2006 8:44 pm
Location: La Vernia, TX

Post by fixit »

fjimp wrote:Sometime ago I was buying stuff at home Depot and almost stumbled over a big box full of Magnets on a Handle. I bought one and used it several times... One great tool to have in the shop.

I haven't seen those for sale but made my own - see pic.[ATTACH]19828[/ATTACH]

It's just a 36" dowel with a small block glued to the end. I drilled a hole in the block, epoxied a rare earth magnet in the hole and put a felt cover on it. Works great.
Attachments
----------------------------------------
Leonard
La Vernia, TX
Wood Goods - Custom Woodwork
EMAIL: woodgoods "at" lavernia "dot" net
PowerPro 520, PowerPro 500 (was my father's 500), SS jointer, SS Mark V mount planer, SS bandsaws (2), belt sander, scroll saw, SS jig saws (2), strip sander, Jointech system, 12" Delta Compound Miter Saw, a small collection of routers, a router table and a Delta Unisaw. All in a 24' x 24' shop.
jhut83
Gold Member
Posts: 50
Joined: Wed Dec 12, 2012 5:21 pm

Post by jhut83 »

I'm still searching for a base. I have plenty to do before I find one anyway. Here's a question for you guys. What are the thoughts on changing the color of a machine? Its not that I don't like the gold and copper, I'm just thinking of having everything powder coated.
User avatar
JPG
Platinum Member
Posts: 35457
Joined: Wed Dec 10, 2008 7:42 pm
Location: Lexington, Ky (TAMECAT territory)

Post by JPG »

jhut83 wrote:I'm still searching for a base. I have plenty to do before I find one anyway. Here's a question for you guys. What are the thoughts on changing the color of a machine? Its not that I don't like the gold and copper, I'm just thinking of having everything powder coated.
Tis thine decision, and thine alone!

PC gotta be more 'durable'.

Just make sure it doesn't go where not welcome.(bore holes)
╔═══╗
╟JPG ╢
╚═══╝

Goldie(Bought New SN 377425)/4" jointer/6" beltsander/12" planer/stripsander/bandsaw/powerstation /Scroll saw/Jig saw /Craftsman 10" ras/Craftsman 6" thicknessplaner/ Dayton10"tablesaw(restoredfromneighborstrashpile)/ Mark VII restoration in 'progress'/ 10
E[/size](SN E3779) restoration in progress, a 510 on the back burner and a growing pile of items to be eventually returned to useful life. - aka Red Grange
jhut83
Gold Member
Posts: 50
Joined: Wed Dec 12, 2012 5:21 pm

Post by jhut83 »

JPG40504 wrote:Just make sure it doesn't go where not welcome.(bore holes)
Ah yes. That would be miserable!
User avatar
terrydowning
Platinum Member
Posts: 1678
Joined: Mon Jul 19, 2010 3:26 pm
Location: Windsor, CO

Post by terrydowning »

Or be wiling to scrape it all out. I thought about Powder Coating mine until I saw the price tag on that.

Rattle can all the way baby.
--
Terry
