Went old school
Moderator: admin
Went old school
I never really liked the legs on the shopsmith so I came up with this. Lots of storage, zero cost. Embarrassed to say this was all made from scrap pine, plywood, mdf and even some cedar. I had way to much!!
- Attachments
-
- IMG_1391.jpeg (122.01 KiB) Viewed 22557 times
-
HopefulSSer
- Platinum Member
- Posts: 605
- Joined: Sun Oct 03, 2021 6:07 pm
- Location: NC
-
larryhrockisland
- Gold Member
- Posts: 269
- Joined: Sun Aug 19, 2007 10:47 pm
Re: Went old school
Very nice, you can’t call it scrap anymore!
Larry Hargrove
Rock Island, Ok
1981 Mark V 500>510>520(98922)
19?? Mark V 500>Power Pro headstock 556176 06-17-11 factory exchange program original serial unknown
1957 Mark V 500 (350389)
1953 10ER
Another 10ER
Bandsaw 2012 Jointer 2012
Bandsaw, Jointer, other goodies
Craftsman table saw, Delta 46-460 Midi lathe
SS 6” Belt Sander w/power stand 1970’s?
Rock Island, Ok
1981 Mark V 500>510>520(98922)
19?? Mark V 500>Power Pro headstock 556176 06-17-11 factory exchange program original serial unknown
1957 Mark V 500 (350389)
1953 10ER
Another 10ER
Bandsaw 2012 Jointer 2012
Bandsaw, Jointer, other goodies
Craftsman table saw, Delta 46-460 Midi lathe
SS 6” Belt Sander w/power stand 1970’s?
-
thunderbirdbat
- Platinum Member
- Posts: 834
- Joined: Sat Aug 08, 2015 11:23 am
- Location: Marion, Iowa
Re: Went old school
Very nice.
Brenda
1998 510 upgraded to a 520, upgraded to power pro with double tilt and lift assist.
1998 bandsaw
2016 beltsander
jointer
overarm pin router
1998 510 upgraded to a 520, upgraded to power pro with double tilt and lift assist.
1998 bandsaw
2016 beltsander
jointer
overarm pin router
-
chapmanruss
- Platinum Member
- Posts: 4187
- Joined: Tue Aug 26, 2014 8:16 pm
- Location: near Portland, Oregon
Re: Went old school
That's really good looking scrap.
_
.
Even more storage than adding the wood box hanging from the Bench Tubes often seen. Building your own base allows for the height to be to the owner's preferred height.
_
- Mark V wood base - rotated.jpeg (56.12 KiB) Viewed 22536 times
Even more storage than adding the wood box hanging from the Bench Tubes often seen. Building your own base allows for the height to be to the owner's preferred height.
Russ
Mark V completely upgraded to Mark 7
Mark V 520
All SPT's & 2 Power Stations
Model 10ER S/N R64000 first one I restored on bench w/ metal ends & retractable casters.
Has Speed Changer, 4E Jointer, Jig Saw with lamp, a complete set of original accessories & much more.
Model 10E's S/N's 1076 & 1077 oldest ones I have restored. Mark 2 S/N 85959 restored. Others to be restored.
Mark V completely upgraded to Mark 7
Mark V 520
All SPT's & 2 Power Stations
Model 10ER S/N R64000 first one I restored on bench w/ metal ends & retractable casters.
Has Speed Changer, 4E Jointer, Jig Saw with lamp, a complete set of original accessories & much more.
Model 10E's S/N's 1076 & 1077 oldest ones I have restored. Mark 2 S/N 85959 restored. Others to be restored.
-
BuckeyeDennis
- Platinum Member
- Posts: 3800
- Joined: Tue Jul 24, 2012 10:03 pm
- Location: Central Ohio
Re: Went old school
Sweet!
I'm tempted to do the same, as storage space is always in short supply in my shop. Have you encountered any downsides to the new configuration?
I'm tempted to do the same, as storage space is always in short supply in my shop. Have you encountered any downsides to the new configuration?
Re: Went old school
I have no regrets at all yet, but I haven’t done a ton on it yet. Time will tell
-
JPG
- Platinum Member
- Posts: 35430
- Joined: Wed Dec 10, 2008 7:42 pm
- Location: Lexington, Ky (TAMECAT territory)
Re: Went old school
Embarrassed????
You should be proud!!!
Re using scrap pine - Any damn fool can possibly make something worthwhile from straight lumber. Although I have run across some who could not even do that!
You should be proud!!!
Re using scrap pine - Any damn fool can possibly make something worthwhile from straight lumber. Although I have run across some who could not even do that!
╔═══╗
╟JPG ╢
╚═══╝
Goldie(Bought New SN 377425)/4" jointer/6" beltsander/12" planer/stripsander/bandsaw/powerstation /Scroll saw/Jig saw /Craftsman 10" ras/Craftsman 6" thicknessplaner/ Dayton10"tablesaw(restoredfromneighborstrashpile)/ Mark VII restoration in 'progress'/ 10E[/size](SN E3779) restoration in progress, a 510 on the back burner and a growing pile of items to be eventually returned to useful life. - aka Red Grange
╟JPG ╢
╚═══╝
Goldie(Bought New SN 377425)/4" jointer/6" beltsander/12" planer/stripsander/bandsaw/powerstation /Scroll saw/Jig saw /Craftsman 10" ras/Craftsman 6" thicknessplaner/ Dayton10"tablesaw(restoredfromneighborstrashpile)/ Mark VII restoration in 'progress'/ 10E[/size](SN E3779) restoration in progress, a 510 on the back burner and a growing pile of items to be eventually returned to useful life. - aka Red Grange
-
edflorence
- Platinum Member
- Posts: 673
- Joined: Thu Jul 20, 2006 8:14 pm
- Location: Idaho Panhandle
Re: Went old school
Very nice! Well-organized storage is super important in a small shop...excellent use of space!
